Self-loading salt and sand disc spreader

Domov » Municipal equipment » Salt and sand spreader » Self-loading salt and sand disc spreader

PR 18

For mounting on tractors.

Type	Capacity	Spreading width	Spreading volume	Overall width	Overall height	Weight
PR 18	1,00 m3 (1000 L)	up to 9 m	0 ÷ 250 g/m²	1800 mm	1150 mm	520 kg
PR 18 (V)	1,45 m3 (1450 L)	up to 9 m	0 ÷ 250 g/m²	1800 mm	1400 mm	590 kg

Standard equipment

Cat. 2 3-point hitch for the rear hydraulic lift mechanism of the tractor
self-loading design with two (2) hydraulic cylinders (the tipping container enables self-loading of the spreading material)
hydraulic drive with powerful planetary hydraulic motor
powered by tractor hydraulics
dosing auger
mixing / crushing rotor located above the dosing auger
self-propelled rotating spreading disc
stainless steel spreading disc
mechanical adjustment of the spreading angle to the left / right (symmetrical or asymmetrical spreading)
protective grid above the mixing rotor
rear LED lamps (traffic signalling equipment)
LED work lamp
latch for opening and closing the discharge hatch
hot-dip zinc plated and painted container – excellent anti-corrosion protection
suitable for spreading sand, salt or mixture of both
ideal for parking lots, roads and walkways
recommended granulation of spreading material between 2 and 8 mm

Additional Equipment

electrical adjustment of the spreading angle to the left / right (instead of mechanical)
container extension (V)
protective tarp
camera
- 7” (177.8 mm) colour LCD display with a bracket
- wireless system – a wireless range of up to 100 meters
- IR night recording vision with a range of up to 1.5 m
- electrical cable with a cigarette lighter plug (ISO 4165 / SAE J563)
additional cover above the dosing auger
for spreading fine salt
cat. 2 or cat. 3 top link (central lever)

Electronic controller PR 18-EK

electronic control of the spreading volume and width directly from the tractor cab (remote control)
control panel installed inside the tractor cab
12V DC power supply
without the path-dependent spreading functionality

electronic controller for path-dependent spreading volume and width directly from the tractor cab (remote control)
control panel installed inside the tractor cab
12V DC power supply

CAUTION!
The tractor must be equipped with a 7 pin signal socket (DIN 9684-1 / ISO 11786)!

Advantages of path-dependent spreading:

ensures the correct spreading dosage (g/m2)
ensures the correct spreading widths (m)
adjustment of the spreading symmetry
optimized work (advantage compared to manual adjustments)
saves spreading material (sand and salt)
economical and environmentally friendly
the operator can focus on driving instead of worrying about spreading (better road safety)
